CANarmatur DPF

Our engine control unit has been specially developed for mobile applications and work machines. It combines robust technology with flexible adaptation and ensures precise control of the engine under all operating conditions.

Scope of delivery:

• CANarmatur DPF engine control unit
• 2 keys (M05052)
• 2 retaining brackets (M08067)
• Sticker

Anwendung
Construction machinery
Communal vehicles
Agricultural machines
Plant engineering
Maritime applications
Special machines

For all engines and special machines with CANbus (SAE J1939).
Transflective, backlit B/W display with high contrast
CANarmatur provides perfect legibility even under poor lighting. Full graphic display, e.g. for standard-compliant DPF symbols

UV-resistant, rugged PA6 housing
Secure installation with retainer or
screw-fastening, 3 x M6
Dependable functioning even in harsh environments.

Communication via CANbus with existing network
Integration of conventional engines in existing CAN bus networks and applications.

Flexibility and control for your electronic systems
Adjustment of all working parameters at the device
Speed adjustment via CAN bus supported
Display of engine operation parameters.
Warning LED or alarm system signals critical engine parameters DPF-support for Deutz EMR4/5, Hatz TICD, Kubota, Yanmar

Safe information about die engine running time and necessary maintenance.
Transparent overview of the operating times.
Password-protected menu settings. Access to relevant functions restricted to authorised personnel.


Further information, the manual, and the leaflat can be found here:
